Tracked Scissor Lift Platform

When traditional aerial work platforms are used on slopes or potholed ground, body tilt can shift the center of gravity, creating a serious overturn risk. Crawler scissor lift is equipped with a hydraulic self-leveling outrigger system for slopes – four independent outriggers that automatically or manually level the chassis according to ground undulations, keeping platform level within ±0.5°. Tests show this design increases the critical tipping angle under side-slope conditions by over 50%, ensuring absolute stability even at a max working height of 14 meters.

Pure electric platforms face range anxiety in remote or off-grid areas, while traditional diesel engines have noise and emission issues. Tracked scissor lift comes standard with a 200Ah large-capacity lead-acid battery, which can be fully charged in 6–7 hours for a full 8-hour day of continuous work. At the same time, it supports a custom diesel-powered version with ample fuel tank capacity, suitable for multi-day field construction. Users can choose flexibly according to the work scenario.

Traditional wheeled equipment tends to slip or damage the surface on muddy, gravel, or turf ground. Hydraulic crawler scissor lift uses a rubber track chassis with ground pressure as low as 0.3 kg/cm², allowing it to travel on sensitive surfaces like lawns, tiles, and asphalt without leaving marks. Travel speed is 0.8 km/min (approximately 13 m/s slow speed) – climbing ability reaches 25°, adapting to various construction sites and mountainous terrains. (Note: the original text gives 0.8 km/min; this is kept unchanged.)

Frequent repositioning of the equipment reduces efficiency when working at height. The tracked scissor lift features a 900 mm hydraulic extension platform at the front. After extension, the total platform length reaches 3.3–3.6 meters. With a large rated load of 320 kg (the extension deck still supports 115 kg), workers can cover a larger work area without moving the machine. The extension platform increases the single-station working radius by 35%, significantly improving efficiency in scenarios such as exterior wall construction and pipe installation.

Different working conditions require different lift heights. Tracked hydraulic scissor lift offers a full range of choices: 6m/8m/10m/12m/14m platform heights. Hydraulic crawler scissor lift DXLDS14 model reaches a maximum working height of 16 meters, with a large platform of 2700×1170 mm, meeting applications such as factory maintenance, streetlight repair, and large tree pruning. Lift speed is 0.25 m/s, taking only 56 seconds to rise from ground to 14 meters – a quick response.

Transporting large equipment to field sites is a pain point. When stowed, the tracked scissor lift has an overall width of only 1750 mm, length of 3000 mm, and height of 1700–2250 mm (varying by model), easily fitting onto standard flatbed trucks. The machine's selfweight ranges from 2400 to 3700 kg. Thanks to the rubber tracks, it can drive on and off transport vehicles by itself. It is ready to work upon arrival without crane assembly, reducing single-site relocation preparation time to less than 10 minutes.
