Manual Pallet Jack Hand Truck
Description
Manual Pallet Jack Hand Truck is commonly used in warehouses as handling equipment and can replace ordinary manual pallet truck. It makes the operation simpler, saves time and effort, and greatly saves labor costs. Full electric mobile pallet truck is used with pallets to transport the goods on the pallets to the shelves. If you have higher shelf heights, then you can also choose one of our other full electric forklift. And you don't need to worry about size. We have different lifting heights and loads for you to choose from. If our standard model doesn't suit you, we can also customize it according to your needs. You only need to tell us the height of your shelf, the width between shelves and required load, and we will recommend the product that best suits you.
Technical Data
|
Model |
|
CBD |
||||||
|
Config-code |
W/0 pedal & handrail |
|
S20 |
S25 |
S30 |
|||
|
With pedal & handrail |
|
ST20 |
ST25 |
ST30 |
||||
|
Drive Unit |
|
Semi-electric |
||||||
|
Operation type |
|
Pedestrian |
||||||
|
Capacity (Q) |
kg |
2000 |
2500 |
3000 |
||||
|
Overall Length (L) |
mm |
1781 |
||||||
|
Overall Width (b) |
mm |
690 |
||||||
|
Overall Height (H2) |
mm |
1305 |
||||||
|
Mi. Fork height (h1) |
mm |
75(85) |
||||||
|
Max. Fork height (h2) |
mm |
195(205) |
||||||
|
Fork dimension (L1*b2*m) |
mm |
1150*160*60 |
||||||
|
MAX Fork Width (b1) |
mm |
530 |
680 |
530 |
680 |
530 |
680 |
|
|
Turning radius (Wa) |
mm |
1608 |
||||||
|
Drive Motor Power |
KW |
1.6AC |
||||||
|
Lift motor power |
KW |
0.8 |
2.0 |
2.0 |
||||
|
Battery |
Ah/V |
210/24 |
||||||
|
Weight w/o battery |
kg |
324 |
329 |
338 |
343 |
352 |
357 |
|
|
Battery weight |
kg |
185 |
||||||

Application
One of our customers from the United States has a factory that produces sugar. After production is completed, workers need to transport the goods on the pallets to the warehouse. Previously, workers could only use manual forklifts, which was very laborious and time-consuming, greatly affecting the efficiency of workers' work. After contacting us through the website, we recommended this electric mobile forklift to him and customized the width of the fork according to the customer's pallet size. Once he received the product, it matched his pallet perfectly and he told us it was a perfect shopping experience. We are also very happy to be able to help him. If you have the same needs, please contact us as soon as possible.
